King Challenger

Jun 1, 2018

King Challenger

Length Overall: 21.30m

Vessel Type: Fishing, Scalloper

Design Search

Download Data Sheet

Principle Dimensions

Length Overall: 21.30 m Length Reg: 18.20 m Breadth Mld: 7.80 m Depth mld: 4.20 m

Capacities

Oil Fuel: 22000 Litres Fresh Water: 13700 Litres Fish Hold: 110 Cubic Meters

Propulsion Machinery

Main Engine Power : 720 Kw @ rpm Propeller Diameter: 2100 mm Propeller Nozzle: yes Bow Thruster: Yes Bow Thruster Power: 70 kw

Deck Machinery

Side Hinging Hydraulic Doors
Hydraulic Shakers

2x Split Winches 14 T 2x Topping Winches 7.7 T 2x Cod End Winches 2 T 1x Landing Crane 8 T/m

Auxilliary Equipment

No. of Aux: 3

2x Caterpillar 3056 DIT 84kw
1x Caterpillar C9
