AQS Trym

Length Overall: 18.50m

Vessel Type: Aquaculture, Catamaran

Principle Dimensions

Length Overall: 18.50 m Length Reg: 17.25 m Breadth Mld: 12.00 m Depth Mld: 4.60 m

Capacities

Oil Fuel: 25000 Litres Fresh Water: 7500 Litres Water Ballast: 20000 Litres Grey Water: 5000 Litres Black Water: 5000 Litres Ships Complement Crew: 6

Performance

Bollard Pull: 21 T Speed: 9 Knots

Propulsion Machinery

Main Engine Power : 374 Kw @ 1800rpm Propeller Diameter: 2200 mm Propeller Nozzle: Yes Drive Type: Conventional Bow Thruster: Yes Stern Thruster: Yes

Deck Machinery

Deck Crane x2
Capstan 5t x2
Capstan 8t
Working/Towing Winch
Tugger Winch
Ship Side Tow Pins
Shark Jaws/Towing Pins
Anchor Winch
Stern Roller
