26.50m Aquaculture Workboat – Kallista Helen – Inverlussa

Jun 10, 2021

Kallista Helen

Length Overall: 26.50m

Vessel Type: Aquaculture

Design Search

Download Data Sheet

Principle Dimensions

Length Overall: 26.50 m Length Reg: 26.00 m Breadth Mld: 12.00 m Depth Mld: 3.50 m Max Draft: 2.75 m

Capacities

Oil Fuel: 54346 Litres Fresh Water: 41663 Litres Water Ballast: 156000 Litres Grey Water: 2911 Litres Black Water: 2911 Litres Ships Complement Crew: 10

Performance

Bollard Pull: 18 T Speed: 12.5 Knots

Propulsion Machinery

Main Engine Power : 492 Kw @ 1800rpm Propeller Diameter: 1500 mm Propeller Nozzle: Yes Drive Type: Conventional Bow Thruster: Yes Bow Thruster Power: 270 hp

Deck Machinery

3 x 14 ton/m Deck Crane
4 x 5T Capstans
Hydrolicing/Thermolicing Equipment

Auxilliary Equipment

No. of Aux: 4

2 x C32 (650kVA)
2 x C4.4 (100kVA)
